| Sistem de operare |
|---|
| OS | Android 11 and Android 13 |
|---|
| GMS certified | GMS certified |
|---|
| CPU | Octa-core 2GHz Processor |
|---|
| Memory | RAM 4GB; Flash 64GB |
|---|
| Security | Supports Verified Boot |
|---|
| Languages support | Multiple languages |
|---|
| Others | Input Chinese/ English; Supports handwriting and soft keyboard |
|---|
| Ecran |
|---|
| Screen Size | 5.0” TFT-LCD HD (720 x 1280) color screen |
|---|
| Touch Panel | Gorilla Glass 3. Ultra sensitive capacitive touch screen,; compatible with gloves and supports wet resistance |
|---|
| Butoane / tastatură |
|---|
| Buttons / Keypad | Side SCAN button x 2 (Left / Right), User-defined function button; (programmable key), volume up/down buttons, on/off button |
|---|
| Cameră |
|---|
| Camera | 8MP front camera; 13M rear camera with LED flash and auto-focus function |
|---|
| Indicatori |
|---|
| Type | LED, Speaker, Vibrator |
|---|
| Simbologii |
|---|
| 2D Barcodes | Support all major 1D and 2D barcodes |
|---|
| RFID |
|---|
| HF RFID | Support HF/NFC, Frequency 13.56Mhz, ISO14443 A/B,; ISO15693, Felica(ISO/IEC18092), Mifare compliance |
|---|
| Interfețe I/O |
|---|
| USB | USB 2.0 (Type-C) |
|---|
| OTG | Yes, over USB Type-C |
|---|
| POGO PIN | Charging via cradle |
|---|
| SIM Slot | Dual SIM , support LTE + LTE |
|---|
| Expansion Slot | MicroSD, up to 256 GB |
|---|
| Audio | One speaker (1.5W / 95±3dB @ 10cm), One receiver; Dual noise-cancelling microphones |
|---|
| Alimentare |
|---|
| Main battery | 3.85V 4250mAh Li-ion battery; Removable |
|---|
| Comunicații |
|---|
| Bluetooth® | Bluetooth® 5 supported |
|---|
| WLAN | 802.11 a/b/g/n/ac/d/e/h/i/j/k/r/v, 2.4G+5GHz, support fast; roaming, VoWiFi, hotspot,; Compliant with WFA, WPA/WPA2 |
|---|
| WWAN | Global:; 4G LTE FDD: B1/B2/B3/B5/B7/B8/B20/B28A/B28B; TDD: B38/B39/B40/B41; 3G WCDMA: B1/B5/B8; 2G GSM: 850,900,1800,1900MHz;; Americas：; 4G LTE FDD-B1/B2/B4/B5/B7/B12/B13/B14/B17/B28A/B28B; TDD-B38/B40/B41; 3G WCDMA: B1/2/4/5/8; 2G GSM: 850,900,1800,1900MHz |
|---|
| GPS | AGPS, GPS, GLONASS, Beidou, Galileo |
|---|
| Sensors | Light Proximity, Accelerometer, e-Compass, Gyroscope sensor |
|---|
| Fingerprint | Optional |
|---|
| Software |
|---|
| MDM Software | SOTI, AirWatch, 42Gears, and MoboLink |
|---|
| Carcasă |
|---|
| Dimensions ( W x H x D ) | 151.1 x 76.8 x 13.7 mm |
|---|
| Weight | 246g (with battery) |
|---|
| Rezistență |
|---|
| Drop Specification | 1.5m, 1.8m with boot case |
|---|
| Sealing | IP67 |
|---|
| Tumble test | 0.5m tumbles for 300 cycles / 600 drops |
|---|
| Condiții de mediu |
|---|
| Operating temperature | -20°C to 60°C |
|---|
| Storage temperature | - 40°C to 70°C (without battery) |
|---|
| Charging temperature | 0°C to 45°C |
|---|
| Relative Humidity | 95% ( non-condensing ) |
|---|
| Accesorii |
|---|
| Accessories | ■ EA520 Battery 3.85V 4250mAh (PN#1400-900063G); ■ USB 2.0 type C cable (PN#1550-905919G); ■ Glass Screen Protector w/ packing, 10pcs/ box (PN#5400-900047G); ■ Boot Case (PN#3210-900031G); ■ Hand Strap with fixed arm- individual package (PN#5400-900046G); ■ Stylus (8mm: PN#384896G / 5.5mm: PN#386534G); ■ Coiled Strap (PN#387610G); ■ 5V/2A Adapter with US plug for terminal & cradle (PN#1010-900058G); ■ 5V/2A Adapter with universal plugs for terminal & cradle (PN#1010- 900067G); ■ Single Slot Charging Cradle* (PN#5000-900092G); ■ Single Slot USB Cradle* (PN#5000-900093G); * Use USB Cable & Power Adapter from EA520; ■ 4-slot Terminal Charging Cradle (PN#5000-900100G, PSU Only); ■ 4-Slot Battery Charging Cradle (PN#5100-900033G, PSU Only); ■ 12V/5A Power Supply in the Multi-slot Cradle (PN#1010-900068G); ■ 3-Pin Power Cord(US) (PN#1010-601551G); ■ 3-Pin Power Cord(EU) (PN#1550-602333G); ■ 3-Pin Power Cord (UK) (PN#1550-602689G); ■ Gun Grip- For EA520 Without Boot Cover On (PN#5500-900097G); ■ EA520 Wearable Kit w/ Bracket, Strap, Pad (PN#3210-900032G); ■ EA520 Vehicle Cradle (PN#5000-900097G); ■ RP902 Bluetooth UHF RFID Pocket Reader; (PN#RP902-33E8S0G(EU),PN#RP902-43A8S0G(US),PN#RP902-43F8S0G (JP)); ■ Soft Belt Holster with Belt Clip (PN#DT3669); ■ Belt Holster (PN#381852); ■ Bracket arm for hand-strap (1x arm and 2x screws) (PN#386078G); ■ Screw set (set contains 2 screws) for bracket (PN#381357G) |
|---|
| Certificări |
|---|
| Regulatory Approvals | CE, FCC, NCC, CCC, SRRC, VCCI, TELEC, RoHS, BQB, N-Mark, BSMI; for battery |
|---|
| Garanție |
|---|
| Hardware Warranty | 12 months |
|---|
| Statement | This product is warranted against defects in workmanship and materials for a period of twelve months from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information. |
|---|
